ATMOS DC25GSP 25 kW Wood and Pellet Combination Boiler

ATMOS DC25GSP Wood and Pellet Boiler – efficient combination boiler with 25 kW

The ATMOS DC25GSP is a modern combination boiler for burning firewood and wood pellets. The heating boiler combines the efficiency of a wood gasification boiler with the convenience of an automatic pellet burner. This allows flexible switching between manual wood operation and automatic pellet operation.

With a wood output of 25 kW, the boiler is particularly suitable for single-family homes and larger residential buildings. The combination of wood gasification and pellet technology enables reliable and economical heat supply.

Highlights and Advantages

• ⭐ Combination boiler for firewood and wood pellets in one heating system
• ⭐ Heating output up to 25 kW for single-family homes and larger buildings
• ⭐ Automatic pellet burner start possible after the wood has burned out
• ⭐ High efficiency of over 92 % for efficient operation
• ⭐ Boiler class 5 according to EN 303-5 for modern biomass heating systems

Application Area & Target Audience

The ATMOS DC25GSP is suitable for various heating systems in residential areas and is frequently used for:

• Single-family homes
• Two-family homes
• Renovations of existing heating systems
• New builds with biomass heating
• Heating systems with buffer storage

Due to the combination of wood and pellet operation, the heating boiler can be used flexibly. Firewood is manually refilled, while pellets can be fed automatically.

Advantages in Everyday Use

The combination boiler enables convenient use of two fuels. When heating with wood, the boiler operates as an efficient wood gasification boiler. As soon as the wood has burned out, the pellet burner can start automatically and continue the heating operation.

This keeps the heating system reliably in operation even when no wood is refilled. This increases comfort and reduces the manual effort required for heating.

Technology & Equipment

The ATMOS DC25GSP features a robust steel construction with a ceramic combustion chamber. Combustion is regulated via multiple thermostats and control components.

• Boiler thermostat for output regulation
• Flue gas thermostat for controlling the induced draft fan
• Safety thermostat (STB) against overheating
• Servo flap for automatic air regulation
• Slot for electronic heating control

The air supply and combustion are automatically adjusted to the fuel used, ensuring stable and efficient operation.

Efficiency & Environment

The ATMOS DC25GSP achieves an efficiency of approximately 92.5 % in wood operation. In pellet operation, the efficiency is around 92.8 %. This allows particularly efficient use of the fuel.

The boiler meets the requirements of boiler class 5 according to EN 303-5 and complies with modern emission standards for biomass heating systems. :contentReference[oaicite:1]{index=1}

Compatibility & System Integration

The combination boiler is typically installed together with a buffer storage tank. This allows the generated heat to be stored efficiently and distributed evenly throughout the building.

The ATMOS DC25GSP can be integrated into various heating systems:

• Buffer storage
• Radiator heating systems
• Underfloor heating systems
• Domestic hot water preparation

Technical Data

Accessories & System Recommendations

For efficient and safe operation, combination with suitable system components such as buffer storage, return temperature elevation, and safety groups is recommended.

Installation and Safety Instructions

Installation must only be carried out by a qualified heating contractor. National regulations as well as the manufacturer's installation and operating instructions must be observed.

FAQ

Download

• Operating Instructions
• Supplement to Operating Instructions
• Exploded View Drawing
• Combination Boiler Brochure
• Pellet Conformity Declaration
