ATMOS DC18GSE 18 kW Wood Gasification Boiler Wood Heating

ATMOS DC18GSE Wood Gasification Boiler 19 kW

The ATMOS DC18GSE Wood Gasification Boiler is a manually fed solid fuel boiler for the efficient combustion of firewood. With a rated heat output of 19 kW, this model is particularly suitable for single-family homes and smaller heating systems.

Thanks to modern wood gasification technology, the boiler achieves high efficiency levels and efficient energy utilization. The DC18GSE meets the requirements of the BImSchV Stage II and achieves the Energy Efficiency Class A+. :contentReference[oaicite:2]{index=2}

Highlights / Advantages

• ⭐ Wood gasification boiler with 19 kW output for single-family homes
• ⭐ Efficiency up to 91.5 % for efficient wood combustion
• ⭐ Energy Efficiency Class A+ according to EU energy labeling
• ⭐ suitable for firewood up to 330 mm in length
• ⭐ meets BImSchV Stage II for modern solid fuel heating systems

Application & Target Audience

The ATMOS DC18GSE is a manually fed wood gasification boiler for modern heating systems using firewood.

Typical applications:

• Heating systems in single-family homes
• Renovation of existing wood heating systems
• New builds with renewable heating technology
• Heating systems with buffer storage
• Heating systems in combination with radiators or underfloor heating

Installation should be carried out by a qualified HVAC specialist.

Everyday Advantages

Wood gasification boilers utilize the energy contained in wood particularly efficiently. In the ATMOS DC18GSE, the wood is first gasified and then completely combusted at high temperatures.

This technology ensures:

• high energy yield from firewood
• reduced emissions
• stable combustion
• economical heating operation

The large filling chamber allows for convenient refilling of firewood and long burning intervals.

Technology & Features

The ATMOS DC18GSE is a classic wood gasification boiler with a suction fan to optimize the combustion process.

Important components include, among others:

• Suction fan to support combustion
• Boiler thermostat and safety thermostat
• Flue gas thermostat
• Belimo actuator for air control
• Thermal discharge safety device

The boiler is operated with firewood with a moisture content of approximately 12–20 %.

Efficiency & Environment

The wood gasification boiler achieves high energy efficiency through the two-stage combustion of wood.

• Energy Efficiency Class: A+
• Boiler efficiency: up to 91.5 %
• Meets BImSchV Stage II

This makes the ATMOS DC18GSE suitable for modern heating systems with renewable fuels.

Compatibility & System Integration

The wood gasification boiler is typically integrated into heating systems with buffer storage. This allows the generated heat to be optimally stored and distributed.

Typical system combinations:

• Buffer storage
• Return temperature elevation
• Radiator heating
• Underfloor heating
• Thermal solar systems

Technical Data

Scope of Delivery

According to the manufacturer, the scope of delivery includes:

• ATMOS DC18GSE Wood Gasification Boiler
• Integrated suction fan
• Control thermostats and safety devices
• Cleaning cover and maintenance components

Accessories & System Recommendations

For the optimal operation of a wood gasification boiler, additional system components are recommended.

Installation & Safety Notes

The installation of the wood gasification boiler must be carried out by a qualified heating specialist. Operation is only permitted with suitable hydraulic integration, safety fittings, and sufficient chimney draft.

The minimum return temperature of 65 °C specified by the manufacturer must be observed.
